Mitsubishi Outlander Charging Guide

The Mitsubishi Outlander PHEV is a plug-in hybrid SUV that combines electric driving for shorter journeys with a petrol engine for longer trips.

Unlike most newer fully electric cars, the Outlander PHEV uses a Type 1 connection for AC charging and CHAdeMO for DC rapid charging on compatible models. A commonly referenced UK version uses a 13.8kWh battery and can charge at up to around 3.6kW AC.

Mitsubishi Outlander PHEV Charging Specifications

Please note that specifications may vary slightly depending on model year and market specification.

Earlier Outlander PHEV models may have a smaller battery, and not all public rapid chargers support CHAdeMO.

Charging the Mitsubishi Outlander PHEV at Home

Charging the Mitsubishi Outlander PHEV at home is convenient because the battery is much smaller than a full electric car battery. With a dedicated home wallbox, a full charge takes around 3 hours 20 minutes, although the vehicle’s onboard AC charger limits charging to around 3.6kW.

A standard three-pin plug can also be used, with a full charge taking around 5 hours. For many owners, charging overnight or during off-peak periods will be more than enough to start each day with a full battery.

Charging Times at Home

Mitsubishi Outlander PHEV Smart Charging Features

The Outlander PHEV can be charged regularly at home to make the most of its electric-only driving capability. Depending on model year and specification, charging timers and vehicle settings may allow owners to schedule charging for convenient or lower-cost periods.

Because the Outlander PHEV is a plug-in hybrid rather than a full EV, regular charging is especially important if owners want to maximise electric running and reduce petrol use on shorter journeys.

How Much Does It Cost to Charge a Mitsubishi Outlander PHEV at Home?

Using a typical UK electricity tariff of 26.35p/kWh:

This is based on a 13.8kWh battery multiplied by 26.35p/kWh. Actual cost will vary depending on tariff, charging losses and whether an off-peak EV tariff is used.

Public Charging for the Mitsubishi Outlander PHEV

The Mitsubishi Outlander PHEV can use public AC destination chargers with the correct Type 1 to Type 2 cable. Some versions also support CHAdeMO rapid charging, although CHAdeMO availability is more limited than CCS on many newer UK charging networks.

Because the Outlander PHEV has a smaller battery than a full EV, public rapid charging can be quick, but it is usually most cost-effective and convenient to charge at home where possible.

Mitsubishi Outlander PHEV Public Charging Times
