Fiat 500e Charging Guide

By Kyle Roache
Last updated: Jun 4, 2026

The Fiat 500e is a compact all-electric city car that combines the iconic Italian styling you expect from a Fiat 500 with efficient electric mobility.

Available with different battery capacities depending on model year and specification, the 500e offers practical charging options at home, at work, and on the public charging network.

Most owners will find home charging the most convenient and cost-effective way to keep their Fiat 500e topped up. The vehicle supports both AC charging via a Type 2 connector for everyday use and DC rapid charging via CCS for faster top-ups when travelling longer distances.

Fiat 500e Charging Specifications

The Fiat 500e is available with two battery sizes in the UK market:

Model variant	Battery capacity	Charging port type	AC Home Charging / Destination Charging Speed	DC Rapid Charging Speed (Public Charging)
Fiat 500e 24kWh	24kWh (23.8kWh usable)	CCS Type 2	Up to 11kW AC	Up to 50kW DC
Fiat 500e 42kWh	42kWh (37.3kWh usable)	CCS Type 2	Up to 11kW AC	Up to 85kW DC

Please note that specifications may vary slightly depending on model year and market specification.

Charging the Fiat 500e at Home

Charging your Fiat 500e at home is the most convenient way to keep the battery topped up. Most UK drivers choose a dedicated 7kW home charging point, which provides significantly faster charging than a standard three-pin socket and allows overnight charging.

The Fiat 500e can accept up to 11kW AC charging when connected to a suitable three-phase charger. However, most UK homes use single-phase electricity supplies, meaning charging speeds are typically limited to 7.4kW.

Using scheduled charging can help owners take advantage of off-peak electricity tariffs, reducing charging costs while ensuring the vehicle is ready when needed.

Charging Times at Home

Charger Power	Model Variant	Estimated Charge Time
2.3kW (3-pin socket)	24kWh	Approximately 10–12 hours
7kW Home Charger	24kWh	Approximately 4 hours
11kW AC Charger	24kWh	Approximately 2.5 hours
2.3kW (3-pin socket)	42kWh	Approximately 18–20 hours
7kW Home Charger	42kWh	Approximately 6 hours
11kW AC Charger	42kWh	Approximately 4 hours

Fiat 500e Smart Charging Features

The Fiat 500e includes several smart charging features designed to improve convenience and efficiency. Through the Fiat mobile app, owners can:

Monitor charging status remotely
Schedule charging sessions
Set charging limits
Pre-condition the cabin while plugged in
View vehicle battery status and range information

These features can help maximise battery efficiency and reduce running costs, particularly when combined with time-of-use electricity tariffs.

How Much Does It Cost to Charge a Fiat 500e at Home?

Using a typical UK electricity tariff of 26.35p/kWh:

Model Variant	Estimated Charging Cost per Single Charge (0–100%)
Fiat 500e 24kWh	Approximately £6.32
Fiat 500e 42kWh	Approximately £11.07

Actual charging costs may vary depending on electricity tariff, battery condition, charging losses and charging habits.

Public Charging for the Fiat 500e

The Fiat 500e is equipped with a CCS charging connector, allowing access to the UK's extensive public charging infrastructure.

Drivers can use AC destination chargers commonly found at shopping centres, hotels and workplaces, as well as rapid and ultra-rapid DC chargers located at motorway services and public charging hubs.

The larger 42kWh model benefits from faster DC charging capability, making it particularly suitable for longer journeys where rapid charging stops are required.

For battery longevity and charging efficiency, DC rapid charging is generally most effective when charging between 10% and 80% state of charge.

Fiat 500e Public Charging Times

Model Variant	Charger Type	Charging Speed
Fiat 500e 24kWh	50kW DC Rapid Charger	10–80% in approximately 30 minutes
Fiat 500e 42kWh	50kW DC Rapid Charger	10–80% in approximately 45 minutes
Fiat 500e 42kWh	85kW DC Rapid Charger	10–80% in approximately 35 minutes
Both Variants	11kW AC Destination Charger	Full charge in approximately 2.5–4 hours depending on battery size

The Fiat 500e's combination of compact dimensions, efficient battery options and fast-charging capability makes it an excellent choice for urban commuting and everyday driving, with flexible charging solutions available both at home and across the UK's growing public charging network.
